Features --
- Also Available in Double Decker Model
- Suitable for HM, PP, LDPE, HDPE, HMHDPE, LLDPE and other plastic films
- Suitable for Plain and Printed BagsL
- Imported Photo Cell can be attached to operate for Printed Bags
- Imported Servo / Stepper Drive and Motor Controlled Bag material drawing system which makes the machine Automatic
- For producing your required bags, just to key-in your required bags length to
- ‘Controller (motion control system)’, the machine will be able to make your required bags length automatically without any manual adjustment
- Variable Speed Drive with Infra-Red Sensor for Unwinder system assuring Automatic Feeding of Bag material to the machine
- Variable Speed Drive for Main motor drive for changing speed of the machine like fan regulator
- Auto Stopping of the Heater/Sealer at the top position to avoid tearing of bags
- Digital Temperature Controller for precise temperature control
- Automatic Belt Conveyor can also be attached for automatic stacking and collection of bags (See Accessories)
- Digital Counter with batch preset, alarm and totalizer
- High production efficiency to save manpower and time
- ‘A Series’ Models has Servo System as Motion Control System which uses Japan make Servo Motor with Servo Drive and Servo Motion Controller
- ‘A Series’ Models have higher accuracy over B Series
| Model (A Series) |
SD 0122 A Series |
SD 0227 A Series |
SD 0332 A Series |
SD 0436 A Series |
SD 0540 A Series |
|---|---|---|---|---|---|
| Working Width | 2” to 20” | 2” to 26” | 2” to 30” | 2” to 34” | 2” to 38” |
| Length Control | 2” to 80” | 2” to 80” | 2” to 80” | 2” to 80” | 2” to 80” |
| Bags Production | 30 - 120 bags / min |
30 - 100 bags / min |
30 - 80 bags / min |
20 - 70 bags / min |
10 - 60 bags / min |
| Power Required | 4 KW | 4.5 KW | 5.5 KW | 5.85 KW | 6.25 KW |
- ‘B Series’ Models has Stepper System as Motion Control System which uses Japan make Stepper Motor with Stepper Drive and Stepper Motion Controller
- ‘B Series’ are Cost Effective compared to A Series
| Model (B Series) |
SD 0122 B Series |
SD 0227 B Series |
SD 0332 B Series |
SD 0436 B Series |
SD 0540 B Series |
|---|---|---|---|---|---|
| Working Width | 2” to 20” | 2” to 26” | 2” to 30” | 2” to 34” | 2” to 38” |
| Length Control | 2” to 80” | 2” to 80” | 2” to 80” | 2” to 80” | 2” to 80” |
| Bags Production | 30 - 110 bags / min |
30 - 90 bags / min |
30 - 70 bags / min |
20 - 60 bags / min |
10 - 50 bags / min |
| Power Required | 4 KW | 4.5 KW | 5.5 KW | 5.85 KW | 6.25 KW |
The product can be customised according to the customer’s requirements for the given attachments and size.
