Features --

• Also Available in Single Decker Model
• Suitable for HM, PP, LDPE, HDPE, HMHDPE, LLDPE and other plastic films
• Not suitable for Printed Bags (See our exclusive product for printed bags)
• Imported Servo/Stepper Drive & Motor controlled Bag material drawing system which makes the machine Automatic
• For producing your required bags, just to key-in your required bags length to ‘ Controller (motion control system) ’, the machine will be able to make your required bags length automatically without any manual adjustment
• Variable Speed Drive with Infra-Red Sensor for Unwinder system assuring Automatic feeding of Bag material to machine
• Variable Speed Drive for Main motor drive for changing speed of the machine like fan regulator
• Auto Stopping of the Heater/Sealer at the top position to avoid tearing of bags
• Digital Temperature Controller for precise temperature control
• Automatic Belt Conveyor can also be attached for automatic stacking and collection of bags (See Accessories)
• Digital Counter with batch preset, alarm and totalizer
• High production efficiency to save manpower and time

Specifications --

• ‘A Series’ Models has Servo System as Motion Control System which uses Japan make Servo Motor with Servo Drive and Servo Motion Controller
• ‘A Series’ Models have higher accuracy over B Series

Model (A Series)	DD 0122 A Series	DD 0227 A Series	DD 0332 A Series	DD 0436 A Series	DD 0540 A Series
Working Width	2” to 20”	2” to 26”	2” to 30”	2” to 34”	2” to 38”
Length Control	2” to 80”	2” to 80”	2” to 80”	2” to 80”	2” to 80”
The production is double as the number of Plastic Rolls are doubled for the Double Decker machine
Bags Production	60 – 240 bags / min	60 – 200 bags / min	60 – 160 bags / min	40 – 140 bags / min	20 – 120 bags / min
Power Required	6 KW	6.75 KW	8 KW	9 KW	9.75 KW

• ‘B Series’ Models has Stepper System as Motion Control System which uses Japan make Stepper Motor with Stepper Drive and Stepper Motion Controller
• ‘B Series’ are Cost Effective compared to A Series

Model (B Series)	DD 0122 B Series	DD 0227 B Series	DD 0332 B Series	DD 0436 B Series	DD 0540 B Series
Working Width	2” to 20”	2” to 26”	2” to 30”	2” to 34”	2” to 38”
Length Control	2” to 80”	2” to 80”	2” to 80”	2” to 80”	2” to 80”
The production is doubled as the number of Plastic Rolls are doubled for the Double Decker machine
Bags Production	60 – 220 bags / min	60 – 180 bags / min	60 – 140 bags / min	40 – 120 bags / min	20 – 100 bags / min
Power Required	6 KW	6.75 KW	8 KW	9 KW	9.75 KW

The product can be customised according to the customer's requirements for the given attachments and size.
