Features --
- Also Available in Double Decker Model
- Cheap and reliable with low investment in the machine
- Suitable for HM, PP, LDPE, HDPE, HMHDPE, LLDPE and other plastic films
- Suitable for Plain Bags only
- Most suitable for huge liner bags
- Mechanical clutch and Brake Mechanism controlled Bag material drawing system
- For Producing your required bags, you need to adjust Screw and Rack Mechanism for getting the approximate size
- Digital Temperature Controller for precise temperature control
- Suitable for those who thrive upon lesser accuracy
| Model (C Series) |
SD 0127 C Series |
SD 0232 C Series |
SD 0336 C Series |
SD 0440 C Series |
SD 0544 C Series |
|---|---|---|---|---|---|
| Working Width | 2” to 26” | 2” to 30” | 2” to 34” | 2” to 38” | 2” to 42” |
| Length Control | 2” to 80” | 2” to 80” | 2” to 80” | 2” to 80” | 2” to 80” |
| Bags Production | 30 - 70 bags / min |
30 - 65 bags / min |
20 - 60 bags / min |
10 - 50 bags / min |
10 - 40 bags / min |
| Power Required | 4 KW | 4.5 KW | 5.5 KW | 5.85 KW | 6.25 KW |
The product can be customised according to the customer's requirements for the given attachments and size.
