The RS series of steam boilers manufactured by us are 3 pass conventional wet back design shell type steam boilers. These are manufactured as per stringent Indian Boiler Regulations (IBR).
These boilers are available in steam output capacities starting from 1TPH to 10TPH. Standard boilers are designed for working pressure of 10.5Kgs/cm2. These boilers can be supplied for pressures upto 17.5 Kgs/cm2. These are supplied as skid mounted units ready for installation.
The robust design and construction of these boilers ensures long service life. Units are supplied with two stage or fully modulating burners as per the oil firing capacity. The RS series of steam boilers have a large steam space and ample evaporation surface for good quality dry steam. They are supplied with a standby feed water pump as a standard accessory.
These units are ideally used for heavy duty installations, where steam demand is high.
| PRODUCT NAME |
|---|
| Oil/Gas Fired, 3 Pass, Shell Type, Flue Tube Steam Boilers |
| Model | Capacity (kg/hr) |
|---|---|
| RS 01 | 1000 |
| RS 02 | 2000 |
| RS 03 | 3000 |
| RS 04 | 4000 |
| RS 05 | 5000 |
| RS 06 | 6000 |
| RS 08 | 8000 |
| RS 10 | 10000 |
Ross steam boilers are extensively used for heating in almost all types of agro industries. Common application examples are as below.
Steam boilers for washing clothes in washing machines and steam is used for steam ironing.
Steam boilers for steam processes in steam stenters in textile industries.
Ross steam boilers are used for curing of concrete cement blocks. The use of steam for curing enables faster curing of cement blocks. The quality of cement bricks also improves.
Steam boilers for manufacturing of ghee . Heating in spray drying for manufacturing of milk powder. For CIP cleaning and manufacturing of by products like Condensed milk, Khowa etc.
Steam boilers for sterlisation & process applications in heating and manufacturing of pharmaceuticals and various drugs.
Steam boilers are used for drying of battery plates & for component surface treatment.
Steam boilers are used for heating air through radiators in drying applications for manufacturing of Coir products like coir matresses.
Steam boilers are used for heating tanks for pretreatment of metal components before painting.
Steam boilers are used for training in educational institutes for product training and demonstration in labs.
Steam boilers for cable manufacturing (curing)
Steam boilers are extensively used for laundry and for heating cooking kettles.
Steam boilers are used in leather processing industries for heating rollers & for process applications.
Steam boilers for thermocole, plywood and paper manufacturing.
Small steam boilers are used in R & D labs for a variety of research applications
For drying applications/ metal pretreatment process applications
The above clip shows design and working of the equipment. All items shown may not be in standard scope of supply.Please refer to the offer for specific scope of supply. We reserve the right to incorporate our latest design and material changes without any notice or obligation.
