Description

• Agitated Nutsche Filter consists of a cylindrical Shell with a welded dished end at the top and a Flat welded end at the bottom
• The vessel is divided into two compartments by means of a perforated plate, provided with Suitable filter cloth.
• The base plate is having arrangement of bolting bar to hold the filter cloth, suitable support mesh is provided under filter cloth to facilitate the flow of filtrate.
• An agitator had a unique design rigid and in “S“ Curved shaped provided inside the vessel to perform the movements of vertical and rotational directions simultaneously, with the help of push Button/PLC based control. The system will take high torque generated during solid discharge and slurring operation.

Process Steps

• Slurry feed
• Filtration
• Washing of filtered cake
• Repeat mix or washing of the cake
• Convection drying of the cake
• Smoothing with compression of the Wet dried cake
• Fully automatic discharge of the Wet or dried cake
• Collection of mother liquor/solvent for further processing or recovery
