| Models |
1.5KVA |
2.4KVA |
3.5KVA |
| Battery Voltage |
24V |
36V |
48V |
| Input AC |
165V-275V 50Hz±2Hz |
| Peak Efficiency |
> 80% |
> 80% |
> 85% |
| Charger |
4-8Amps -Adjustable |
| Output |
Mains Mode-Two Step Buck Boost |
| Inverter |
MOSFET with H.F. PWM |
| Indications |
|
| 1.Visual |
Mains ON, Inverter ON, Overload, Battery Low, charging ON, System ON |
| 2. Audio |
Mains to Inverter at Start, Battery Low early warning and overload |
| 3. Input |
MCB, Over/Under Voltage cut-off |
| Protections |
|
| 1. Battery |
Fuse Link |
| 2. Output |
Electronic Trip for Overload and Short Circuit |
| Change Over |
Static Switch as standard |
| Models |
2.4/36V |
3.5/48V |
| Load* Option |
A |
B |
A |
B |
C |
| Tube |
9 |
9 |
12 |
10 |
15 |
| Fan |
7 |
8 |
10 |
7 |
13 |
| CFL |
7 |
8 |
8 |
8 |
9 |
| TV |
2 |
1 |
1 |
2 |
1 |
| Computer |
0 |
1 |
0 |
0 |
1 |
| Dot Printer |
0 |
1 |
0 |
0 |
1 |
| Mixer / W Machine |
1 |
0 |
0 |
1 |
0 |
| Refrigerator |
0 |
0 |
1 |
1 |
0 |
| Air Condition (1 ton) |
0 |
0 |
0 |
0 |
0 |
| Water Motor/Cooler |
0 |
0 |
0 |
0 |
0 |
Bunglows, Hospitals, Restaurants, Parlours, Petrol Pumps, Showrooms & Offices to run Refrigerator, Air Condition, Pump, Electric Motor, Cooler, Suction Machine, X-ray Machine, Dental Chair, etc.
