F - 320/6 Colour Automatic Flexographic Printing Machine
Specifications :
• 4 Colour Printing Unit with IR Dryer
• 1 Colour With UV Dryer
• 5 Set of Ceramic Anilox Rollers
• Web guide For Paper Movement
• Ceramic Anilox Rollers
• Automatic Unwind and Rewind Tension Controller of Mistubishi
• Printing Unit Adopt 360 Degree to Regulate Each Edition for • Single Colour Backside
• Printing Turn Bar Unit The Ink Roller Can Leave Automatically
• When The Machine Is Braked, And It Will Still Run
• At A Low Speed to Avoid the Ink ti be Dried.
• Lamination Unit.
• Rotary Die-cutting Unit
• Variable Speed of Frequency Conversion
• Can do Unwind, Print, Coat, ir Dry and
• Laminate and Rewing at Some Time.
• Speed : 50 M/Min.
• Max Print Width : 310 mm.
• Max Web Width : 320 mm.
• Precisions : 0.1 mm.
• Weight : 2200 kgs.
• Diemesions : 2000 x 1500 x 3000 (MM)
• Total Power : 7 KW

4120-E
4 COLOUR PRINTING + LAMINATION + STAMPING / DIE CUTTING MACHINE
Specifications :
• Paper Width :- 215 mm Maximum
• Printing Area :- 205 x 410 mm
• 4 Colour Area :-205 x 95 mm
• 3 Colour Area :-205 x 130 mm
• Die Cut Area :-220 x 250 mm
• Stamping Area:-220 x 200 mm
• Auto Numbering Chese (Extra)
• Speed : 5000 Stroke / hr. Maximum
• Paper Feeding Electronic System
• Paper Feeding Electronic System
• Main motor :-3 HP. 3 Phase AC. , Variable Speed
• Weight :-2300 Kgs. (Approx)
• Machine Control With Fully Digital Electronic Control
• Production Counter Control With Auto Stop

2530-E"
STAMPING + EMBOSSING + DIE CUTTING + COMPUTER HOLES MACHINE
Specifications :
• Paper Width :- 300mm Maximum
• Double stamping Unit Area :- 300 mm x 250mm
• 4 Colour stamping Area :-300 x 125mm
• Electronic Cross Foil Feeding
• Die Cut Area :- 300 x 250mm
• Embossing Unit
• Computer Sprocket :- 17 Holes Unit
• Paper Feeding Electronics System
• Speed :- 5000 Stroke / Hrs. Maximum
• Weight :-2500 Kgs. (Approx)
• Machine Control with Fully Digital Electronic Control
• Production Counter Control with Auto Stop

FQ-320 FQ-320 Automatic Trademark Slitting machine

High Speed Label Sitting & Rewinding Machine wih Maximum Paper Width :320 mm
