Infrastructure
Discover Group of Companies was established in April 2006 and is an ISO-9001:2008 certificated company. Our company constitutes tools and precision work and Auto Stamping units. These are a registered partnership firm. We focus on stable high quality and professional service as well as reasonable price while controlling our production and quality according to ISO standards. Supported by our very strong & professional engineering team and good equipped quality center, we are the right company to supply our customers with very stable high quality products and professional service.
15000 SQ. FEET LAND WITH INDUSTRIAL SHED # 150HP POWER SANCTIONED
MACHINE LIST:-
| SR NO | MACHINE DESC. | FRAME | POWER REQ.IN HP | RAM STROKE | BED LENGTH | BED WIDTH | SHUGHT HEIGHT | RAM LENGTH | RAM WIDTH | CUSHION STROKE | CUSHION AREA |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 50 T PRESS | C-FRAME | 5 | 75 | 760 | 550 | 350 | 410 | 230 | NA | NA |
| 2 | 75 T PRESS | C-FRAME | 7.5 | 75 | 760 | 530 | 350 | 450 | 220 | NA | NA |
| 3 | 100 T PRESS | H-FRAME | 10 | 100 | 770 | 760 | 315 | 610 | 350 | NA | NA |
| 4 | 160 T PRESS | C-FRAME | 10 | 160 | 1000 | 700 | 550 | 700 | 550 | 160 | 400 X 300 |
| 5 | 160 T PRESS | C-FRAME | 10 | 160 | 900 | 650 | 500 | 600 | 450 | 160 | 400 X 300 |
| 6 | 250 T PRESS | C-FRAME | 20 | 210 | 1750 | 900 | 425 | 1150 | 700 | 110 | 1100 x 400 |
| 7 | 400 T PRESS | H-FRAME | 30 | 300 | 2130 | 925 | 800 | 2100 | 900 | 150 | 1800 x 600 |
| 8 | 400 T PRESS S | H-FRAME | 30 | 400 | 2150 | 1370 | 800 | 2150 | 1350 | 200 | 1800 X 600 |
| 9 | 600 T PRESS | H-FRAME | 45 | 400 | 2500 | 1550 | 850 | 2400 | 1200 | 200 | 2100 x 900 |
| 10 | 600 T PRESS | H-FRAME | 45 | 400 | 3350 | 1250 | 1170 | 3350 | 1250 | 200 | 2100 x 900 |
| 11 | 1000 T PRESS | H-FRAME | 125 | 450 | 3350 | 1550 | 1200 | 330 | 1500 | 225 | 3000 x 1200 |
| 12 | HYDRAULIC PRESS BRAKE | CAPACITY : 4MM X 3300MM | |||||||||
WELDING AND ASSEMBLY SHOP:-
| SR NO | MACHINE DESC. | QTY. |
|---|---|---|
| 1 | SHEARING MACHINE 6.35MM X 3100MM | 1 |
| 2 | SHEARING MACHINE 3MM X 1250MM | 1 |
| 3 | CO2 WELDING 350A | 5 |
| 4 | 25KVA PROJECTION / SPOT WELDING M/C | 1 |
| 5 | PIPE BENDING MACHINE (SINGLE AXIS SEMI AUTOMATIC # CAPACITY F 40mm ) | 1 |
| 6 | ABRASSIVE CUTTING MACHINE | 1 |
TOOL ROOM AND MACHINNING SHOP:-
| SR NO | MACHINE DESC. | QTY. |
|---|---|---|
| 1 | CNC MACHINING CENTRE | 1 |
| 2 | VMC MACHINING CENTRE | 1 |
| 3 | RADIAL DRILLING MACHINE | 3 |
| 4 | MILLING MACHINE | 1 |
| 5 | LATHE MACHINE | 2 |
| 6 | SURFACE GRINDER | 1 |
| 7 | M1TR BOARING M/C | 1 |
