UNIT I

Unit-1 : Injection Molding Tooling

Established On : Open 1st Qtr 2008
Built Area : 10,000 (Sq ft)

Unit-1 : Injection Molding Tooling

Tool Room Facility Infrastructure

Unit-1 : Tool Room Facility Infrastructure

Office Area

Unit-1 : VMC Shop

Unit-1 : VMC Machines

PINNACLE
RPM 10000

Unit-1 : VMC Machines

AGIE CHARMILLS MIKRON VCP 600
RPM 20000

Unit-1 : VMC Machines

MAKIN0 S33
RPM 20000

Unit-1 : VMC Machines

MAZAK MOLD MAKER 2000
RPM : 25000

Unit-1 : VMC Machines

MAKINO S56
RPM 12000

Unit-1 : Tool Room Facility Infrastructure

EDM /Wire Cut / CMM Shop

Unit-1 : EDM

EDGE-3 EDM (MAKINO)

Unit-1 : EDM

CHMER EDM -A6040L

Unit-1 : EDM & EDM Drilling

EDM - Edge 3i - MAKINO

Unit-1 : EDM & EDM Drilling

EDM Drilling (Precision Machine)

Unit-1 : Wire Cut Machine

Mitsubishi Wire Cut Machine
(400 x 300 x 250)

Unit-1 : Surface Grinder

Okamoto-1

Unit-1 : Surface Grinder

Okamoto-2
500 x 200 mm

Unit-1 : Surface Grinder

EQUITOP SURFACE GRINDER

Unit-1 : Conventional Machines Setup

JIG BORING Machine

Unit-1 : Conventional Machines Setup

M1TR DRILLING Machine

Unit-1 : Conventional Machines Setup

RADIAL DRILLING Machine

Unit-1 : Conventional Machines Setup

Lathe Machine

Unit-1 : Inspection & Measurement

Inspection of parts on :
Coordinate Measuring Machine (CMM)CONTURA G2 7/10/6 RDS

Unit-1 : Inspection & Measurement

Inspection of parts on:
Vision Measuring Machine (VMM)
