Split Wheels
Klassic Wheels has the capacity to manufacture wheels for applications ranging from wheels for Agricultural, 2 Wheelers, 3 Wheelers, e-Auto etc. Some of the wheels manufactured by Klassic are as follows. Not all items are listed. Please contact us for any size or application you do not see below
Split Wheels
| Type | Segment | Part Code | Rim Size in Inch (Diameter) | Rim Size in Inch (Width) | Bore Diameter | Bolt Hole PCD | Bolt Hole Dia. | No of Bolt Holes | Offset |
|---|---|---|---|---|---|---|---|---|---|
| Split Wheel | Agriculture | FGO3030001 | 8 | 3 | 136 | 174 | 8.5 | 4 | – |
Split Wheels
| Type | Segment | Part Code | Rim Size in Inch (Diameter) | Rim Size in Inch (Width) | Bore Diameter | Bolt Hole PCD | Bolt Hole Dia. | No of Bolt Holes | Offset |
|---|---|---|---|---|---|---|---|---|---|
| Split Wheel | 3 Wheeler | FGA3030007 | 8 | 3 | 137 | 174 | 8.5 | 4 | – |
Split Wheels
| Type | Segment | Part Code | Rim Size in Inch (Diameter) | Rim Size in Inch (Width) | Bore Diameter | Bolt Hole PCD | Bolt Hole Dia. | No of Bolt Holes | Offset |
|---|---|---|---|---|---|---|---|---|---|
| Split Wheel | 3 Wheeler | FGP3030011 | 8 | 3 | 136 | 164 | 10.5 | 4 | – |
Split Wheels
| Type | Segment | Part Code | Rim Size in Inch (Diameter) | Rim Size in Inch (Width) | Bore Diameter | Bolt Hole PCD | Bolt Hole Dia. | No of Bolt Holes | Offset |
|---|---|---|---|---|---|---|---|---|---|
| Split Wheel | 3 Wheeler | FGL3030001 | 8 | 3 | 52.5 | 100 | 10.5 | 4 | 16.5 |
