Oil Packing Machines

A vertical Form-Fill-Seal Intermittent machine suitable to pack oil, Shampoo, Ghee etc.

Specification :
• Mechanical cam driven operation with fixed speed.
• Motorized film roll unwinding mechanism.
• Machine equipped with motorized batch printing & eye mark sensor.
• Perforation system to produce chain of pouches.

Body of machine : Fabricated in mild steel, Powder coated
All part coming in contact with the product are of stainless steel
Packing material : Any heat seal able Laminated or Three/Five Layer co-extruded 60-100 micron max 325mm width
Sealing type : Center / side seal-Impels / continues sealing
Filling of product : Gravity filling / Volumetric Piston filler
Electric : 230 volt, Single Phase
Motor : 1 H.P.Single Phase
Other : * Available in Mechanical & Pneumatic version



Features :
• Fully Automatic Machine available in Mechanical as well as Pnuematic Version.
• Filling is through Pistons as well as Gear Pumps.
• Machine stops for "No Plastic".
• Available in single Head and Double Head Versions.
• Available in Center Sealing and side sealing.

Model	Filling Range	Pouch Length	Pouch Width	Electric Power	Output
SVP-20	0-20 gm	30-140 mm	18-90 mm	230 Single Ph	40-60 P/Min
SVP-100	20-100 gm	30-180 mm	30-120 mm	230 V Single Ph	30- P/Min
SVP-250	50-250 gm	30-250 mm	30-160 mm	230 V Single Ph	25-30P/Min
SVP-1000	50-250 gm	100 -260 mm	60-220 mm	230 V Single Ph	15 P/Min

Product Range : A perfect machine suitable for Edible Oil Cocount Oil, Lube Oil, Grease, Paints.
