Unified Thread Gauges

BASIC DIMENSIONS & GAUGING PRACTICE : ANSI/ASME B1.2-1983
Practice of gauges as per BS 1580-2007 & Gauging practice to B.S. 919 (1) -2007 on request IS 2334-2001
CLASS OF FIT :
Screw Plug :2B ( Medium)
Srew Rings :2A ( Medium)

Get a quote

Size
Nom. Dia	Pitch
NO. 0 (0.06")	80 UNC
NO. 1 (0.073")	64 UNF
NO. 1 (0.073")	72 UNC
NO. 2 (0.086")	56 UNC
NO. 2 (0.086")	64 UNF
NO. 3 (0.099")	48 UNC
NO. 3 (0.099")	56 UNF
NO.4 (0.06")	40 UNC
NO.4 (0.06")	48 UNF
NO.5 (0.086")	40 UNC
NO.5 (0.086")	44 UNF
NO.6 (0.138")	32 UNC
NO.6 (0.138")	40 UNF
NO.8 (0.164")	32 UNC
NO.8 (0.164")	36 UNF
NO.10 (0.190")	24 UNC
NO.10 (0.190")	32 UNF
NO.12 (0.216")	24 UNC
	28 UNF
	32 UNEF
1/4" (0.250")	20.UNC
1/4" (0.250")	28 UNF
32 UNEF
5/16" (0.3125")	18 UNC
	24 UNF
	32 UNEF
3/8" (0.375")	16 UNC
	24 UNF
	32 UNEF
7/16" (0.4375")	14 UNC
	20 UNF
	28 UNEF

Size
Nom. Dia	Pitch
1/2" (0.500")	13 UNC
	20 UNF
	28 UNEF
9/16" (0.5625")	12 UNC
	18 UNF
	20 UNF
	24 UNEF
5/8" (0.625")	11 UNC
	18 UNF
	20 UN
	24 UNEF
11/16" (0.6875")	12 UNC
	18 UNF
	20 UN
	24 UNEF
3/4" (0.750")	10 UNC
	12 UN
	16 UNF
	20 UNEF
13/16" (0.8125")	12 UN
	16 UNF
	20 UNEF
7/8" (0.875")	9 UNC
	12 UN
	14 UNF
	16 UN
	20 UNEF
15/16" (0.9375")	12 UN
	16 UN
	20 UNEF

Size
Nom. Dia	Pitch
1"	8 UNC
	12 UNF
	14 UNS
	16 UN
	20 UNEF
1-1/16" (1.0625")	8 UN
	12 UN
	16 UN
	18 UNEF
1-1/8" (1.125")	7 UNC
	12 UNF
	16 UN
	18 UNEF
1-3/16" (1.1875")	7 UNC
	12 UNF
	16 UN
	18 UNEF
1-1/4" (1.250")	7 UNC
	8 UN
	12 UNF
	16 UN
18 UNEF
20 UN
1-5/16" (1.3125")	8 UNC
	12 UN
	16 UN
	18 UNEF
	20 UN

Size
Nom. Dia	Pitch
1-3/8" (1.375")	6 UNC
	8 UN
	12 UNF
	16 UN
	18 UNEF
	20 UN
1-7/16" (1.4375")	6 UNC
	8 UN
	12 UN
	16 UN
	18 UNEF
	20 UN
1-5/8" (1.625")	8 UN
	12 UN
	16 UN
	18 UNEF
	20 UN
1-11/16" (1.6875")	8 UN
	12 UN
	16 UN
	18 UNEF
	20 UN
1-3/4" (1.750")	5 UN
	8 UN
	12 UN
	16 UNEF
	20 UN
1-13/16" (1.8125")	8 UN
	12 UN
	16 UNEF
	20 UN
