Chassis |
DCP CAPACITY |
|---|---|
| TATA / LEYLAND / EICHER / BHARAT BENZ 16 TON GVW | 500 KG X 2/ 1000 KG X 1 OR 500 KG X 1 WATER + FOAM + PUMP |
| TATA / LEYLAND / EICHER / BHARAT BENZ 25 TON GVW | 1000 KG + WATER + FOAM + PUMP OR 2000 Kg x 2 DCP + REEL + MONITOR |
| Body | Crew 1+5 – SCBA attachment / aluminum sandwich panels |
| Pump | UL - 3000 lpm @ 10bar, 4000 lpm @10 bar. & 300 lpm @ 40 bar - Optional. |
| Hose Reel | DCP REEL. 25 MTR X 2. |
| Features | 1) Nitrogen Cylinder Storage Rack. with spare cylinders. 2) Optional electrical Control panel with LED Indication. 3) Optional - Water, Foam, Ultra High Pressure and High Low Pressure Pump system. 4) Optional DCP Monitor. 5) Tank and pipeline Fabricated as per ASME Code - VIII |
| Fitted Accessories | Ext. ladder, light bar, P.A. system siren etc. |
