KTP 99 WLC

Features

• Technology :
• Micro controller based software technology
• Current Range / HP :
• 2 – 22 Amps. / 1 to 7.5 HP DOL or as required.
• Display :
• Digital Voltmeter 200 – 500 V
• Digital Ammeter 1 – 30 Amps.
• Protections :
• Phase Failure (Supply Side)
• Phase Failure (Motor Side)
• Reverse Phase (Supply Side)
• Voltage and Current Unbalance
• Electronic Overload (Site Settable)
• Remote sensing Dryrun (Site Settable)
• High / Low Voltage (Site Settable)
• Extreme High Current (Fixed at 26 Amps.)
• Special Features :
• Fully Automatic Two Tank Universal Water Level Controller Suitable for Float Switches / Metal Sensors or Magnetic Switches
• Indications for Upper Tank Full & Lower Tank Empty.
• Timers :
• Power ON Timer – 3 – 300 sec. (Site Settable)
• Dryrun Auto start timer – OFF – 5 to 720 mins. (Site Settable) Pump will restart automatically after tripping with Dryrun so no need to go repeatedly to restart the pump and we get maximum water output from a low yield boring.
• MCB :
• 3 Pole, 32 Amp. C Series MCB
• Short circuit as per IEC60899-1
• Starter :
• AC Coil Branded Contactors.
