KDP 99 WLC

Features

• Technology :
• Micro controller based software technology
• Current Range / HP :
• 2 – 20 / 2 – 26 / 2 – 45 Amps for 2 / 3 / 5 HP.
• Display :
• Digital Voltmeter (100 to 300 V)
• Digital Ammeter (2 – 20 / 2 – 26 / 2 – 45 Amps. / as per current range)
• Protections :
• Starting Capacitor Cut Off Timer
• Electronic Overload ( Site Settable )
• Remote sensing Dryrun ( Site Settable )
• High / Low Voltage ( Site Settable )
• Extreme High Current( Short Circuit )
• Special Feature :
• Two Tank Fully Automatic Universal Water Level Controller with Auto start On Power Failure
• Indications for Upper Tank Full & Lower Tank Empty
• Timers :
• Motor Off Timer (SS) – 5 to 720 mins.
• Power On Timer For Auto start
• Dryrun Auto Start Timer (SS) Off – 5 to 720 mins.
• Switches :
• Heavy Duty DC Coil Contactor
• Capacitors :
• Starting Capacitor and Running Capacitors as per HP.
