Infrastructure & Facilities
We have a state-of-the-art infrastructure facility equipped with advance manufacturing technologies and machines that assist us to fabricate the best quality products. This unit is segregated into various departments such as manufacturing, quality control, research & development, warehouse & packaging, sales & marketing, etc. The maintenance technologies that we adopt are one of the best in the industry that ensure that the machinery functions smoothly and efficiently at all time giving optimum performance. Our infrastructural base is facilitated with following machinery and instruments.
PRODUCTION FACILITIES
MACHINARY-
1. CNC TURNING CENTRE:– SL-10 (HAAS, USA make) Year of Manufacturing - 2006
Capacity: - Max. Dia 320 mm with 350 mm axial between centre length. Hollow spindle with 51mm dia and live tailstock.
2. CNC TURNING CENTRE:– SL-30 (HAAS, USA make) Year of Manufacturing - 2007
Capacity: - Max. Dia 482 mm with 864 mm axial between centre lengths. Hollow spindle with 76mm dia and programmable live tailstock.
3. CNC TURNING CENTRE:– PILTUS 25T (LMW make) Year of Manufacturing - 2007
Capacity: - Max. Dia 380 mm with 550 mm axial between centre lengths. Hollow spindle with 51 mm dia and live tailstock.
4. CNC TURNING CENTRE:– LL20 T3 (LMW make) Year of Manufacturing - 2007
Capacity: - Max. Dia 350 mm with 330 mm axial between centre lengths. Hollow spindle with 51mm dia and live tailstock.
5. CNC TURNING CENTRE:– Smart Turn (LMW make) Year of Manufacturing - 2007
Capacity: - Max. Dia 250 mm with 280 mm axial between centre lengths. Hollow spindle with 51mm dia and tailstock.
6. CNC TURNING CENTRE:– DX-200 (JYOTI make) Year of Manufacturing – May 2011
Capacity: - Max. Dia 365 mm with 500 mm axial between centre lengths. Hollow spindle with 51mm dia and tailstock.
7. CNC TURNING CENTRE:– DX-200 (JYOTI make) Year of Manufacturing – Oct 2011
Capacity: - Max. Dia 365 mm with 500 mm axial between centre lengths. Hollow spindle with 51mm dia and tailstock.
8. VERTICAL MACHINING CENTRE:- VF3(HAAS, USA make) Year of Manufacturing - 2006
Capacity :- Table size – 1219 x 457 mm, Maximum weight on table – 1588 Kg, X travel = 1016 mm, Y travel = 508 mm, Z travel = 635 mm. Spindle taper BT40, Spindle RPM = 7000 rpm, 4th Axis provision with HRT 210 indexing unit having 0 degree resolution available.
9. VERTICAL MACHINING CENTRE:- MDC500 (HAAS, USA make) Year of Manufacturing - 2007
Capacity: - Table size – 508 x 324 mm, Maximum weight on table – 850 Kg, X travel = 508 mm, Y travel = 356 mm, Z travel = 508 mm. Spindle taper BT40, Spindle RPM = 7500 rpm, side mounted tool changer – Capacity 24+1
10. VERTICAL MACHINING CENTRE:- VF1(HAAS, USA make) Year of Manufacturing - 2008
Capacity :- Table size – 660 x 356 mm, Maximum weight on table – 1361 Kg, X travel = 508 mm, Y travel = 406 mm, Z travel = 508 mm. Spindle taper BT40, Spindle RPM = 7000 rpm, 4th Axis provision with HRT 210 indexing unit having 0 degree resolution available.
11. VERTICAL MACHINING CENTRE:- SLIM3 PC(MAKINO, make) Year of Manufacturing - 2011
Capacity :- Table size – 510 x 380 mm, Maximum weight on table – 1161 Kg, X travel = 508 mm, Y travel = 385 mm, Z travel = 508 mm. Spindle taper HSK A50, Spindle RPM = 8000 rpm, 4th Axis provision.
12. INDUSTRIAL WASHING MACHINE BASKET DIA 800 MM :- Aqua Clean System Make, Year of Manufacturing - Dec 2008
Capacity :- Rotary Basket size – Dia 800 mm, Maximum weight on Basket – 500 Kg, Cleaning Agent – Hot Water with anti rust cleaning agent Techniclean-SF Castrol make.
13. HORIZONTAL GRAVITY DIE CASTING MACHINE (2 Nos) :- Renu Enterprises Make Year of Manufacturing - 2012
Capacity :- Platen Size – 800 x 600 mm, Both Side ejection. Locking Pressure – 100 HP
14. HOLDING CUM MELTING FURNACE :- Energy Systech Make , Year of Manufacturing - 2012
Capacity :- 300 Kg ( 150 Kg per Hour). Power – 36 Kw
OTHER FACILITY
-Radial Drill M/c. FOSTER make-1 No
