We , NISHAKA PNEUMATICS are equipped with modern machinery and cutting-edge technology for the testing of raw material and thus, we carry out stern quality examinations of the same at the initial stages. As we have lot of experience we can supply premium range of Pneumatic Rotary Actuators in the market.
Following is detail description :

• Available in Double Acting and Single Acting Spring Return.
• Torque output ranging from :3 Nm To 430 Nm.
• Trouble Free for more than one million cycles operation.
• Working Pressure 80 P.S.I.
• Operating Pressure 3 to 10 Kg.
• Mounting interface-Centre port, NAMUR for solenoid valves, ISO 5211 for valves and self centering actuator.
• Zero play actuators.
• Rotation 0 to 90@ (Degree) Rotary Motion.
• Pneumatic Rotary Actuators

Specification
Type	Pneumatics Rotary Actuator Is Used For Butterfly Valve, Ball Valve, Plug Valve Etc.
Design	Centre port Compact Design With Aluminium confirming. Powerful & Compactable Piston Harden Pinion. No Metal To Metal Contact, Namur Mounting.
Size For D/A	50045 / 50056 / 50069 / 50080 / 50101 / 50125 / 50160
Size For S/A	90045 / 90056 / 90069 / 90080 / 90101 / 90125 / 90160
Operation	0 to 90@ (Degree) Rotary Motion
Working Pressure	80 P.S.I
Operating Pressure	3 to 10 Kg
Material	Aluminum Hard Anodizing
Media	Air
