SPOOL TYPE SOLENOID VALVES are versatile. They consist of a spool inside a cylinder which is mechanically or electrically actuated. The position of spool controls the fluid flow. For the convenience of our customers, concerns of the organization is to make available only quality approved products to the buyers and thus we check the entire range at all stages.
| Specification | |
| Type | 3 way and 4 way Spool Type solenoid Valves. |
| Manufacturing Range Sizes | 1/8" BSP / 1/4" BSP/ 1/2" BSP |
| Orifice | 5mm for 1/8" BSP,6.5mm For 1/4" BSP And 12.5 for 1/2" BSP |
| Pressure | 2.5 to 10 Kg/cm2 |
| Media | Air, Water & Non Corrosive Liquids & Gases |
| Body | Anodized Aluminium Body Brass & stainless steel Against Specific Orders |
| Manual Overdrive | Optional |
| Data | Epoxy Mounded, Water Proof, Continuous Duty Coils, 6 to 230 V AC & 9.5 Watts Low Watts as per request |
