Premier Engineers

SPECIFICATIONS
SICHT No.	Length of bolt	Dia. of bolt	Production P.M.	Motor H.P. & R.P.M.
1.	1/2" - 1"	1/16" - 1/8"	80 - 90	1 X 1440
2.	1/2" - 2"	3/16" - 1/4"	60 - 80	3 X 1440
3.	3/4" - 3"	1/4" - 3/8"	50 - 60	5 X 1440
4.	1" - 4"	5/16" - 1/2"	40 - 45	7.5 X 1440
5.	1½" - 5"	3/8" - 5/8"	30 - 35	15 X 1440
6.	2" - 6"	1/2" - 3/4"	25 - 30	20 X 1440
* Design, output, dimensions & weight are subject to modification.

SPECIFICATIONS
SICRT No.	Length of bolt	Dia. of bolt	Production P.M.	Motor H.P. & R.P.M.
1.	1/2" - 1½"	1/8" - 3/16 "	70 - 100	2 X 1440
2.	1/2" - 2"	3/16" - 1/4"	60 - 80	3 X 1440
3.	3/4" - 3"	1/4" - 3/8"	50 - 60	5 X 1440
4.	1" - 4"	5/16" - 1/2"	40 - 45	7.5 X 1440
5.	1½" - 5"	3/8" - 5/8"	30 - 35	15 X 1440
6.	2" - 6"	1/2" - 3/4"	25 - 30	20 X 1440
* Design, output, dimensions & weight are subject to modification.
