• ±1 Micro m repeat accuracy
• Activating pin made of unbreakable zirconium oxide
• 30 cN minimum activating force
• Pointed activating pins
• 2-wire normally closed contact (NC) and 3-wire normally open contact (NO)
• Lateral approach also possible to 30° (spherical activating pins)
• Also in protection class IP 67

MY-COM A
	Characterstics Conical brass housing front M8 fine pitch thread	Dimension:M8 x 0, repeat accuracy :< 1μm Resolution
response time:	Output :NC (mechanical)

MY-COM B
	Characterstics Brass housing Flat housing front M8 fine pitch thread	Dimension:M8 x 0, repeat accuracy :< 1μm Resolution
response time:	Output :NC (mechanical)

MY-COM D
	Characterstics Robust browned brass housing Spherical metal tip Protection class IP 67 Lateral approachpossible to 30°	Dimension:M16 x 0,5 repeat accuracy :< 1μm Resolution
response time:	Output :NC (mechanical) NO (PNP/NPN)

MY-COM E
	Characterstics Brass housing M6 fine pitch thread Spherical hard metal tip Lateral approach possible to 30°	Dimension:M6 x 0,5 repeat accuracy :< 1μm Resolution
response time:	Output :NC (mechanical) NO (PNP/NPN)

MY-COM F MY-COM G
	Characterstics Brass housing Long M8 fine pitch thread	Dimension:M8 x 0,5 repeat accuracy :< 1μm Resolution
response time:	Output :NC (mechanical) NO (PNP/NPN)

MY-COM M
	Characterstics Brass housing M8 fine pitch thread Protection class IP 67	Dimension:M8 x 0,5 repeat accuracy :< 1μm Resolution
response time:	Output :NC (mechanical) NO (PNP/NPN)

MY-COM H MY-COM L
	Characterstics Brass housing M8 fine pitch thread Spherical ruby tip Protection class IP 67	Dimension:M8 x 0,5 repeat accuracy :< 1μm Resolution
response time:	Output :NC (mechanical) NO (PNP/NPN)
