| Product Description : |
2K Polyurethane top Coat based on Acrylic Resin |
| Recommended use : |
Automobile Products, Electrical Products, Machine Tools |
| Features : |
Excellent durability
Smooth & glossy finish.
Excellent toughness |
| Physical Properties : |
Colour Shade |
As per customer requirement |
|
Volume Solids |
45 (± 2 %) |
|
D.F.T. |
30 to 40 microns |
|
Theoretical spreading rate |
8 to 9 sq. meter @ D.F.T. 25-30 μ |
|
Flash point |
Base - 24° C ; Hardner - 28° C |
|
Sp. Gravity |
Base 1.20 (± 0.1) kg / Ltr.
Hardner 1.05 (± 0.05) kg / ltr |
| Surface Preparation : |
Surface to be coated should be completely clean , dry and free from contamination.
Remove oil & grease with suitable solvent or detergent
Remove rust, mill scale and other loose material by wire mesh / abrasive blasting |
| Application : |
Application Conditions |
Ambient temperature shall be above 10°C and relative humidity shall be below 85%.
Adequate ventilation shall be provided in confined spaces |
|
Mixing |
Stir each component with mechanical stirrer before mixing |
|
Mixing ratio |
Paint : 4 parts, Hardner : 1 part , Thinner : 1 parts (by volume)
|
|
Application method |
By air assisted spray gun |
|
Pot Life |
Minimum 4 hours at 30°C
(Pot life may be reduced at higher temperature) |
|
Drying Time |
Surface Dry – 10 to 15 minutes
Touch Dry – 1.5 to 2 hours |
|
Over Coating |
Minimum 6 hours |
|
Minimum 6 hours |
Epoxy Primer OR P.U. Primer |
| Shelf Life |
Base : 12 months; Hardner : 6 months from the date of mfg. |
TWO PACK EPOXY TOP COAT
| Product Description : |
EPOXY TOP COAT |
| Recommended use : |
Transformers , Radiators , Machine Tools, MS Tanks |
| Features : |
Excellent Chemical Resistance
Smooth & glossy finish.
Excellent adhesion |
| Physical Properties : |
Colour Shade |
As per customer requirement |
|
Volume Solids |
50 (± 5 %) |
|
D.F.T. |
30 to 40 microns |
|
Theoretical spreading rate |
8 to 9 sq. meter @ D.F.T. 25-30 μ |
|
Flash point |
Base - 26° C ; Hardner - 28° C |
|
Sp. Gravity |
Base 1.20 (± 0.1 ) kg per Ltr.
Hardner 0.90 (± 0.05) kg / Ltr |
| Surface Preparation : |
Surface to be coated should be completely clean , dry and free from contamination.
Remove oil & grease with suitable solvent or detergent
Remove rust, mill scale and other loose material by wire mesh / abrasive blasting |
| Performance Properties : |
Acid / Alkali Resistance- for 10% solution – 24 hours
Salt Spray – passes 230 hours |
| Application : |
Application Conditions |
Ambient temperature shall be above 10°C and relative
humidity shall be below 85%.
Adequate ventilation shall be
provided in confined spaces |
|
Mixing |
Stir each component with mechanical stirrer before mixing |
|
Mixing ratio |
Paint : 2 parts, Hardner : 1 part , Thinner : 1 parts (by volume) |
|
Application method |
By air assisted spray gun |
|
Pot Life |
Minimum 4 hours at 30°C
(Pot life may be reduced at higher temperature) |
|
Drying Time |
Surface Dry – 20 to 30 minutes
Touch Dry – 3 to 4 hours |
|
Over Coating |
Minimum 8 hours |
|
Typical undercoat |
Epoxy Primer |
| Shelf Life |
Base : 12 months; Hardner : 12 months from the date of mfg. |
TWO PACK EPOXY COAL TAR BLACK
| Product Description : |
EPOXY Anticorrosive Primer |
| Recommended use : |
Steel Structures, traction batteries, Chemical plants , MS Tanks |
| Features : |
Excellent Chemical Resistance
High Performance Corrosion control
Quick Drying
Can be applied on wet surface |
| Physical Properties : |
Colour Shade |
Black |
|
Volume Solids |
55 (± 5 %) |
|
D.F.T. |
30 to 40 microns |
|
Theoretical spreading rate |
9 to 10 sq. meter @ D.F.T. 25 μ |
|
Flash point |
Base - 26° C ; Hardner - 28° C |
|
Sp. Gravity |
Base 1.25 (± 0.1 ) kg per Ltr.
Hardner 0.85 (± 0.05) kg / Ltr |
| Surface Preparation : |
Surface to be coated should be completely clean , dry and free from contamination.
Remove oil & grease with suitable solvent or detergent
Remove rust, mill scale and other loose material by wire mesh / abrasive blasting |
| Performance Properties : |
Acid / Alkali Resistance- for 10% solution – 24 hours
Salt Spray – passes 300 hours |
| Application : |
Application Conditions |
Ambient temperature shall be above 10°C and relative
humidity shall be below 85%.
Adequate ventilation shall be
provided in confined spaces |
|
Mixing |
Stir each component with mechanical stirrer before mixing |
|
Mixing ratio |
Paint : 4 parts, Hardner : 1 part , Thinner : 1.5 parts (by volume) |
|
Application method |
By air assisted spray gun/ airless spray gun |
|
Pot Life |
Minimum 6 hours at 30°C
(Pot life may be reduced at higher temperature) |
|
Drying Time |
Surface Dry – 20 to 30 minutes
Touch Dry – 4 to 5 hours |
|
Typical undercoat |
Epoxy Primer |
| Shelf Life |
Base : 12 months; Hardner : 12 months from the date of mfg. |
CHLORINATED RUBBER PAINT
| Product Description : |
Protective and chemical resistance paint |
| Recommended use : |
Steel Structures, traction batteries, Chemical plants , MS Tanks |
| Features : |
Excellent Chemical Resistance & Acid –Alkali resistance
Water resistance
Quick Drying |
| Physical Properties : |
Colour Shade |
All Pigmented shades (except white) |
|
Volume Solids |
40 (± 5 %) |
|
D.F.T. |
25 to 30 microns |
|
Theoretical spreading rate |
5 to 6 sq. meter @ D.F.T. 25 μ |
|
Flash point |
23° C |
|
Sp. Gravity |
Base 1.10 (± 0.1 ) kg per Ltr. |
| Surface Preparation : |
Surface to be coated should be completely clean , dry and free from contamination.
Remove oil & grease with suitable solvent or detergent
Remove rust, mill scale and other loose material by wire mesh / abrasive blasting |
| Performance Properties : |
Acid / Alkali Resistance- for 10% solution – 24 hours
Salt Spray – passes 300 hours for total system |
| Application : |
Application Conditions |
Ambient temperature shall be above 10°C and relative
humidity shall be below 85%.
Adequate ventilation shall be
provided in confined spaces |
|
Mixing |
Stir each component with mechanical stirrer before mixing |
|
Mixing ratio |
Paint : 2 parts, Thinner : 1 part (by volume) |
|
Application method |
By air assisted spray gun |
|
Drying Time |
Surface Dry – 10 to 15 minutes
Touch Dry – 15 to 20 minutes |
|
Typical undercoat |
Epoxy Primer |
| Shelf Life |
Base : 12 months from the date of mfg. |
SYNTHETIC Q.D. ENAMELS
| Product Description : |
Quick Drying Enamel Paints |
| Recommended use : |
Steel Structures, Auto body –Commercial Vehicles & Auto parts |
| Features : |
Excellent drying properties
Smooth & Glossy Finish
Good Durability |
| Physical Properties : |
Colour Shade |
As per customer's requirement |
|
Volume Solids |
52 (± 3 %) |
|
D.F.T. |
25 to 30 microns |
|
Theoretical spreading rate |
8 to 9 sq. meter @ D.F.T. 25 μ |
|
Flash point |
26° C |
|
Sp. Gravity |
Base 1.10 (± 0.1 ) kg per Ltr. |
| Surface Preparation : |
Surface to be coated should be completely clean , dry and free from contamination.
Remove oil & grease with suitable solvent or detergent
Remove rust, mill scale and other loose material by wire mesh / abrasive blasting |
| Performance Properties : |
Weathering- 100 hrs. (10% gloss reduction accepted)
Salt Spray – passes 140 hours for total system |
| Application : |
Application Conditions |
Ambient temperature shall be above 10°C and relative
humidity shall be below 85%.
Adequate ventilation shall be
provided in confined spaces |
|
Mixing |
Stir well with mechanical stirrer before application |
|
Mixing ratio |
Paint : 4 parts, Thinner : 1 part (by volume) |
|
Application method |
By air assisted spray gun |
|
Drying Time |
Surface Dry – 25 to 30 minutes
Touch Dry – 4 to 5 hours |
|
Typical undercoat |
Q.D. Primer |
| Shelf Life |
12 months from the date of mfg. |
STOVING PAINT
| Product Description : |
Stoving Enamel Paint |
| Recommended use : |
Auto body –Commercial Vehicles , Two wheelers , Auto components & steel Furniture |
| Features : |
Excellent Hardness
Smooth & Glossy Finish
Good Durability |
| Physical Properties : |
Colour Shade |
As per customer's requirement |
|
Volume Solids |
42 (± 3 %) |
|
D.F.T. |
30 to 35 microns |
|
Theoretical spreading rate |
5 to 6 sq. meter @ D.F.T. 25 μ |
|
Flash point |
23° C |
|
Sp. Gravity |
Base 1.10 (± 0.1 ) kg per Ltr. |
| Surface Preparation : |
Surface to be coated should be completely clean , dry and free from contamination.
Remove oil & grease with suitable solvent or detergent
Remove rust, mill scale and other loose material by wire mesh / abrasive blasting |
| Performance Properties : |
Weathering – 400 hrs. (10% gloss reduction accepted)
Salt Spray – passes 180 hours for total system
Petrol – Diesel resistance - Passes |
| Application : |
Application Conditions |
Ambient temperature shall be above 10°C and relative
humidity shall be below 85%.
Adequate ventilation shall be
provided in confined spaces |
|
Mixing |
Stir well with mechanical stirrer before application |
|
Mixing ratio |
Paint : 3 parts, Thinner : 1 part (by volume) |
|
Application method |
By air assisted spray gun |
|
Stoving schedule |
120° C (± 5° C) for 30 minutess |
|
Typical undercoat |
Stoving Primer |
| Shelf Life |
12 months from the date of mfg. |
CHLORINATED RUBBER PAINT
This Epoxy mastic coating is specially developed for application for untreated or unprepared surface. It can be apply on wet surface. It has excellent adhesion & Chemical resistance.
APPLICATION: This coating can be used as universal primer for steel structure, pipelines, tanks, Chemical plants. This primer can be over coated with Epoxy, P.U. or quick drying paints.
PRODUCT SPECIFICATIONS :
Excellent adhesion
Excellent Chemical Resistance
Longer Pot Life
Can achieve High D.F.T
500-700 hours salt spray
