Steel Industrial Structures & Grating
Steel Industrial Structures & Grating
We provide Quick drying primers and paints to various steel structure and grating manufacturing industries. These coating products are most suitable for protecting metals from corrosion.
These products have excellent adhesion and hardness.
TWO PACK EPOXY ZINC PHOSPHATE GREY PRIMER
| Product Description : | EPOXY Anticorrosive Primer |
| Recommended use : | Steel Structures, traction batteries, Chemical plants , MS Tanks, Machine tools & Transformers |
| Features : |
| Physical Properties : | Colour Shade | Grey |
| Volume Solids | 48 (± 3 %) | |
| D.F.T. | 30 to 40 microns | |
| Theoretical Coverage | 9 to 10 sq. meter @ D.F.T. 25 μ | |
| Flash point | Base - 26° C ; Hardner - 28° C | |
| Sp. Gravity | Base 1.40 (± 0.1 ) kg per Ltr. | |
| Hardner 0.90 (± 0.05) kg / Ltr |
| Surface Preparation : | |
| Performance Properties : | Acid / Alkali Resistance- for 10% solution – 24 hours Salt Spray – passes 250 hours |
| Application : | Application Conditions | Ambient temperature shall be above 10°C and relative humidity shall be below 85%. Adequate ventilation shall be provided in confined spaces |
| Mixing | Stir each component with mechanical stirrer before mixing | |
| Mixing ratio | Paint : 3 parts, Hardner : 1 part , Thinner : 1 part (by volume) | |
| Application method | By air assisted spray gun | |
| Pot Life | Minimum 4 hours at 30°C (Pot life may be reduced at higher temperature) |
|
| Drying Time | Surface Dry – 20 to 25 minutes Touch Dry – 2 to 3 hours |
|
| Over Coating | Minimum- 8 hours maximum – 7 days |
| Shelf Life | Base : 12 months; Hardner : 12 months from the date of mfg. |
TWO PACK EPOXY RED OXIDE ZINC PHOSPHATE PRIMER
| Product Description : | EPOXY Anticorrosive Primer |
| Recommended use : | Steel Structures, traction batteries, Chemical plants , MS Tanks, Machine tools & Transformers |
| Features : |
| Physical Properties : | Colour Shade | Red oxide |
| Volume Solids | 52 (± 3 %) | |
| D.F.T. | 30 to 40 microns | |
| Theoretical Coverage | 9 to 10 sq. meter @ D.F.T. 25 μ | |
| Flash point | Base - 26° C ; Hardner - 28° C | |
| Sp. Gravity | Base 1.50 (± 0.1 ) kg per Ltr. | |
| Hardner 0.90 (± 0.05) kg / Ltr. |
| Surface Preparation : | |
| Performance Properties : | Acid / Alkali Resistance- for 10% solution – 24 hours Salt Spray – passes 230 hours |
| Application : | Application Conditions | Ambient temperature shall be above 10°C and relative
humidity shall be below 85%. Adequate ventilation shall be provided in confined spaces |
| Mixing | Stir each component with mechanical stirrer before mixing | |
| Mixing ratio | Paint : 3 parts, Hardner : 1 part , Thinner : 1 part (by volume) | |
| Application method | By air assisted spray gun | |
| Pot Life | Minimum 4 hours at 30°C (Pot life may be reduced at higher temperature) |
|
| Drying Time | Surface Dry – 20 to 25 minutes Touch Dry – 1 to 2 hours |
|
| Over Coating | Minimum- 8 hours maximum – 7 days |
| Shelf Life | Base : 12 months; Hardner : 12 months from the date of mfg |
TWO PACK EPOXY RED OXIDE ZINC PHOSPHATE PRIMER
| Product Description : | EPOXY Anticorrosive Primer |
| Recommended use : | Steel Structures, traction batteries, Chemical plants , MS Tanks, Machine tools & Transformers |
| Features : |
| Physical Properties : | Colour Shade | Red oxide |
| Volume Solids | 52 (± 3 %) | |
| D.F.T. | 30 to 40 microns | |
| Theoretical Coverage | 9 to 10 sq. meter @ D.F.T. 25 μ | |
| Flash point | Base - 26° C ; Hardner - 28° C | |
| Sp. Gravity | Base 1.50 (± 0.1 ) kg per Ltr. | |
| Hardner 0.90 (± 0.05) kg / Ltr. |
| Surface Preparation : | |
| Performance Properties : | Acid / Alkali Resistance- for 10% solution – 24 hours Salt Spray – passes 500 hours |
| Application : | Application Conditions | Ambient temperature shall be above 10°C and relative
humidity shall be below 85%. Adequate ventilation shall be provided in confined spaces |
| Mixing | Stir each component with mechanical stirrer before mixing | |
| Mixing ratio | Paint : 3 parts, Hardner : 1 part , Thinner : 1 part (by volume) | |
| Application method | By air assisted spray gun | |
| Pot Life | Minimum 5 hours at 30°C (Pot life may be reduced at higher temperature) |
|
| Drying Time | Surface Dry – 10 to 15 minutes Touch Dry – 2 to 3 hours |
|
| Over Coating | Minimum- 8 hours maximum – 7 days |
| Shelf Life | Base : 12 months; Hardner : 12 months from the date of mfg |
TWO PACK EPOXY ZINC RICH GREY PRIMER
| Product Description : | EPOXY Anticorrosive Primer |
| Recommended use : | Steel Structures, traction batteries, Chemical plants , MS Tanks, Machine tools & Transformers |
| Features : |
| Physical Properties : | Colour Shade | Grey |
| Volume Solids | 52 (± 3 %) | |
| D.F.T. | 40 to 50 microns | |
| Theoretical Coverage | 5 to 6 sq. meter @ D.F.T. 40 to 50 μ | |
| Flash point | Base - 28° C | |
| Sp. Gravity | Base 1.80 (± 0.1 ) kg per Ltr. | |
| Hardner 0.90 (± 0.05) kg / Ltr. |
| Surface Preparation : | |
| Performance Properties : | Acid / Alkali Resistance- for 20% solution – 24 hours Salt Spray – passes 500 hours |
| Application : | Application Conditions | Ambient temperature shall be above 10°C and relative
humidity shall be below 85%. Adequate ventilation shall be provided in confined spaces |
| Mixing | Stir each component with mechanical stirrer before mixing | |
| Mixing ratio | Paint : 3 parts, Hardner : 1 part , Thinner : 1 part (by volume) | |
| Application method | By air assisted spray gun | |
| Pot Life | Minimum 5 hours at 30°C (Pot life may be reduced at higher temperature) |
|
| Drying Time | Surface Dry – 15 to 20 minutes Touch Dry – 1 to 2 hours |
|
| Over Coating | Minimum- 8 hours maximum – 7 days |
| Shelf Life | Base : 06 months; Hardner : 06 months from the date of mfg |
