Leak Testing Machines
Ball and Pin Pressing Machines
- 1st Station Ball Plug Press from One Side & Pin Press from Other Sides
- 2nd Station Leak Testing of the Plugged Holes for Both the Sides
- Ball & Pin Escapement is Automatic. Operator Will Load & Unload Cam Shaft Only
- All Pressing by Pneumatic Cylinders
- Control Through PLC Logic
Air Leak Testing for Carburettor
- Manual loading of job
- This is Three Passage Micro Leak Testing Machine for Carburettor
- All Three Passages are Simultaneously Checked for Leak rate
- Equipped with Ok job punch marking provision
- PLC controlled
Air Leak Testing for Camshaft
- Manual loading of job
- Passage open confirmation provision
- Hole confirmation with help of pressure switch
- Leak testing at 2 bar air pressure
- Leak rate confirmed with Leak Tester
- Cycle start with two hand push button
- PLC controlled with OK-Not Ok indication
