Servo Press
Target Wheel & Plug Press
- 5 station auto pressing and inspection machines
- Station 1: Loading of job and cycle start (Manually)
- Station 2: Job will be oriented to pressing position with help of servo motor
and scanning of 2D matrix.
- Station 3: Target wheel pressing with servo motors.
- Station 4: Plug pressing with servo motors.
- Station 5: Depth/Height inspection.
- All pressing data and inspection data will be recorded with reference to
scanned 2D Matrix.
- No major setup change required during model change. Simple and quick setup
change saving time.
- Cycle Start with two hand push button.
- Machine equipped with all necessary poka-yokes.
- All errors are displayed on HMI, making fault finding easy and saving time.
Target Wheel Press
- 4 station auto pressing and inspection machines
- Station 1: Loading of job
- Station 2: Job will be oriented to pressing position with help of servo motor
and scanning of 2D matrix.
- Station 3: Target wheel pressing with servo motors.
- Station 4: Depth/Height inspection.
- All pressing data and inspection data will be recorded with reference to
scanned 2D Matrix.
- No major setup change required during model change. Simple and
quick setup change saving time.
- Cycle Start with two hand push button.
- Machine equipped with all necessary poka-yokes.
- All errors are displayed on HMI, making fault finding easy and saving time.
Seal Assembly
- Manual loading of job at loading station.
- Seals will be stacked, and singling will be done at each cycle.
- Pressing positions of job and seal are achieved with servo motors.
- Pressing of seal with servo motosr.
- No setup change required during model change.
- Cycle Start with two hand push button.
- Machine equipped with all necessary poka-yokes.
- All errors are displayed on HMI, making fault finding easy and saving time.
