5 Valve Manifold Direct Mounted - H Manufacturers And Suppliers
PART NO : 3VM-DM-H
DESCRIPTION :Designed for direct mounting of differential pressure transmitters. For remote mounting two oval / kidney flanges are used for connecting process pipe to manifold Block These manifold block incorporate five Valves, two main valves for process Isolation, two Valves For vent, one valves for equalizing.
CONNECTION- Process : Flanged
- Instrument : Flanged
- Drain/vent : 1/4"NPT(F)
- @ 25°c' Room temperature
- Hydrostatic : Body : 620kg/cm2g
- Seat :413kg/cm2
- Pneumatic : Seat : 40kg/cm2
- PTFE : Standard
- GRAPHOIL : Temperature above 180°c
- A105, A182 Gr 304 SS, A182 Gr F 316 SS Monel, Hastalloy.
- CS :Zinc plated and Dichromated
- SS :Natural
