Technical Specifications:

• State of the art MOPA FIBER Laser technology
• Marking Area – 150*150mm, 220*220mm
• Laser power 20W/30W/50W/70W/100W
• Marking Speed – 7000mm/s, 12000mm/s
• 100000 working hours life of Laser
• M² – <1.6
• Series – EP/RM/YLP
• Beam Delivery Cable length – 2m/3m
• Average Power(W) – 20W/30W/50W/70W/100W
• Peak Power(kW) – >12
• Pulse Energy(mJ) – 1.0(WF32)
• Full Power Range (kHz) – 20-1000
• Operating Range (kHz) – 1-1000
• Pulse width range(ns) – 3-500
• Pulse Tune Wave forms -40
• CW mode with modulation – Yes
• Modulation range in CW (kHz) – 0-200
• Typical output power stability – 3%
• Power Supply Voltage (V) – 24V
• Power Supply Current (A) – <10A

Features:

• 2 years warranty on Laser
• High Speed
• High Accuracy
• Air cooled
• Maintenance Free
• No consumables required
• Minimal power consumption
• Highly customizable
• 2D, 3D, On the fly and Rotary marking (Optional)
