When any engine goes into repair, some spare parts may need to be replaced to keep the engine running in smooth condition. This replacement may be needed for different reasons. The most predominant reason is the accidental damage of any spare parts or the simple act of a spare part reaching the threshold of its durability.

Replacing the spares: But no matter how the spare is repaired, there comes a time when it needs to be replaced. And while replacing the parts, trust only genuine Comet Spares. The genuine parts designed by the brand understand the specifications of the particular model, thereby making sure that the spare part fits perfectly.

The genuine parts that fit: In the case of spare parts, each model has its own specific place and position and only those designed by the company would directly fit properly with the model. Even those parts designed for the different models of the same brand would not fit with each other. This is why the genuine spare parts should be used for all engines.

Replacement guarantee: Genuine spare parts come with the replacement guarantee from the company and therefore can be replaced in case of any problems. The company provides a 12 months or 24 months warranty for the spare parts and when the problems arise within this time duration the products can be replaced.


Fast moving spare part list - PPW5A-5 HP WC 1500 RPM


Sr.No. Code Name of the part Qty. per Engine Qty .per packed box
1 A01 L.P.SET MOD. WC 87.5MM 1 4
2 50008 BEARING CR PORT PR 306 1 10
3 17198 Gasket Cyl Hd 87.5ppw Cac 1 10
4 15120 Spring Valve Port "2d" 2 50
5 15124 Valve Guide Portable 2 12
6 15119 Valve In & Ex Portable 2 12
7 15123 Valve Cup Modified Port 2 12
8 12130 Valve Collet Pair 2 12
9 A18 Dip Stick & O Ring Portable 1 12
10 15128 Valve Rocker Portable 2 6
11 15176 Bush V R Port Msp 991 2 6
12 51451 Oil Seal 30mm Portable 1 10
13 51452 Oil Seal 35mm Big Port 1 10
14 20264 Pipe Leak Off Lwe 8.5"L(B 1 12
15 20244 Pipe Tank To Fltr Lwe[R- 1 12
16 15173 Pipe Filtr-Pump Sing P/C( 1 12
17 A34 Cam Gear Assly 5/1500 1 2
18 15135 Crank Gear Portable 1 2
19 19163 Crank Shaft Ppw 5 To 8mod[R- 8] 1 2
20 50403 Screw Hex M6x12l Flng Typ-Crank 1 2
21 17122 Lub Oil Pump Assy Ac Port 1 4
22 17126 Lub Oil Pump Port 010 1 2
23 17128 Lub Oil Pump Port 020 1 2
24 50036 Bearing Tr 501349/501310 2 4
25 19169 Pushrod Ppw&A Mod 2 6
26 15151 Valve Tappet Portable 2 6
27 15165 Fuel Rocker Roller Type Port 1 6
28 51478 Rubber Ring Liner 85 Ppw 1 20
29 15160 Pipe High Pr Wc Port Spl 1 6
30 60019 Gasket Packing Set Wc Por 1 10
31 19110 Shims Hsg Big Cpw 0.005" 2 12
32 19111 Shims Hsg Big Cpw 0.010" 2 12
33 14121 Fuel Filter Upto 6.5hp St 1 2
34 14144 Air Cl.Asy Sml With Clp Comet 1 2
35 14159 Exh Silencer With Flange Comet 1 2
36 A10 Con Rod Assly Port. 1 2
37 15163 Starting Handle Portable 1 4
38 17110 Fulcrum Pin Ac Ppw&A Port 1 6
39 51337 Woodruff Key Portable 1 6
40 51336 Flywheel Key Portable 1 6
41 19167 P R Set 87.5 (2+1)3534tces 1 6
42 17187 Pipe Lo Fp To Rs Ppw&A 1 6
43 50050 Bearing Con Rod Port 010 1 4
44 50051 Bearing Con Rod Port 020 1 4
45 20283 Fuel Tank Comet Colt 7 Ltr. 1 2
46 52170 Gov Brkt Assy Var Sp Port 1 2
47 52171 Var Sp Rachet Asly Port 1 2

Fast moving spare part list- PPW8D -8HP WC 2600 RPM


Sr.No. Code Name of the part Qty. per Engine Qty .per packed box
1 A01 L.P.SET MOD. WC 87.5MM 1 4
2 50008 BEARING CR PORT PR 306 1 10
3 17198 GASKET CYL HD 87.5PPW CAC 1 10
4 15120 SPRING VALVE PORT "2D" 2 50
5 15124 VALVE GUIDE PORTABLE 2 12
6 15119 VALVE IN & EX PORTABLE 2 12
7 15123 VALVE CUP MODIFIED PORT 2 12
8 12130 VALVE COLLET PAIR 2 12
9 A18 DIP STICK & O RING PORTABLE 1 12
10 15128 VALVE ROCKER PORTABLE 2 6
11 15176 BUSH V R PORT MSP 991 2 6
12 51451 OIL SEAL 30MM PORTABLE 1 10
13 51452 OIL SEAL 35MM BIG PORT 1 10
14 14111 PIPE LEAK-OFF SINGLE CONV.(B) 1 12
15 20244 PIPE TANK TO FLTR LWE[R- 1 12
16 15173 PIPE FILTR-PUMP SING P/C( 1 12
17 A33 CAM GEAR ASSLY 5/2200 1 2
18 15135 CRANK GEAR PORTABLE 1 2
19 19163 CRANK SHAFT PPW 5 TO 8MOD[R- 8] 1 2
20 50403 SCREW HEX M6X12L FLNG TYP-CRANK 1 2
21 20157 LUB OIL PUMP ASSLY PPW8C 1 4
22 17209 LUB OIL PUMP ASS A/C 0.10 1 2
23 17210 LUB.OIL PUMP ASS A/C 0.20 1 2
24 50036 BEARING TR 501349/501310 2 4
25 19169 PUSHROD PPW&A MOD 2 12
26 15151 VALVE TAPPET PORTABLE 2 6
27 32133 ROLLER TYPE FUEL ROCKER φ 22MM 1 6
28 51478 RUBBER RING LINER 85 PPW 1 20
29 15160 PIPE HIGH PR WC PORT SPL 1 12
30 60019 GASKET PACKING SET WC POR 1 10
31 19110 SHIMS HSG BIG CPW 0.005" 2 12
32 19111 SHIMS HSG BIG CPW 0.010" 2 12
33 14121 FUEL FILTER UPTO 6.5HP ST 1 4
34 14146 AIR CLNR TV2 CLP (KOEL) 1 2
35 20163 EX.SILENCER LARGE 8/2600 1 2
36 A10 CON ROD ASSLY PORT. 1 2
37 15163 STARTING HANDLE PORTABLE 1 4
38 17110 FULCRUM PIN AC PPW&A PORT 1 6
39 51337 WOODRUFF KEY PORTABLE 1 12
40 51336 FLYWHEEL KEY PORTABLE 1 12
41 19167 P R SET 87.5 (2+1)3534TCES 1 10
42 17187 PIPE LO FP TO RS PPW&A 1 6
43 50050 BEARING CON ROD PORT 010 1 4
44 50051 BEARING CON ROD PORT 020 1 4
45 17158 FUEL TANK PPW&A COMET 1 2
46 52170 GOV BRKT ASSY VAR SP PORT 1 2
47 52173 VAR SPD RACHET PPW8/2600 1 2

Fast moving spare part list- CUB5W-5 HP WC 2600 RPM


Sr.No. Code Name of the part U/M Qty. per Engine Qty .per packed box
1 A24 L P SET  5/2600 WC CUB JA No 1 4
2 50081 BEARING CR PR LWE 2600 No 1 10
3 20230 GASKET CYL HD 80MM CUB WC No 1 10
4 15120 SPRING VALVE PORT "2D" NO 2 50
5 15124 VALVE GUIDE PORTABLE NO 2 12
6 15119 VALVE IN & EX PORTABLE No 2 12
7 15123 VALVE CUP MODIFIED PORT NO 2 12
8 12130 VALVE COLLET PAIR PR 2 12
9 A36 CUB DIP STICK WITH 0 RING NO 1 10
10 15128 VALVE ROCKER PORTABLE NO 2 10
11 15176 BUSH V R PORT MSP 991 NO 2 10
12 51533 OIL SEAL GEAR COVER LWE NO 1 10
13 51534 OIL SEAL BIG HSG LWE NO 1 10
14 20264 PIPE LEAK OFF LWE 8.5"L(B no 1 12
15 20244 PIPE TANK TO FLTR LWE[R- NO 1 12
16 15173 PIPE FILTR-PUMP SING P/C( NO 1 12
17 A26 CAM GEAR ASSLY 5/2600 CUB NO 1 2
18 20108 CRANK GEAR LWE NO 1 2
19 20118 CRANK SHAFT CUB WC,AC[R-1 NO 1 2
20 50403 SCREW HEX M6X12L FLNG TYP-CRANK NO 1 2
21 20112 LUB OIL PUMP ASSLY LWE NO 1 6
22 20154 LUB OIL PUMP CUB5 010 NO 1 6
23 20155 LUB OIL PUMP CUB5 020 NO 1 2
24 50083 BEARING TR 30207 LWE NO 1 6
25 20238 GOV PUSHROD CUB WC,AC NO 2 12
26 20234 VALVE TAPPET LWE CUB NO 2 12
27 32133 ROLLER TYPE FUEL ROCKERØ22mm NO 1 12
28 51532 RUBBER RING LINR 80MM LWE NO 1 20
29 20270 H P PIPE WC CUB[R- 2] NO 1 6
30 20235 GASKET PKG SET CUB WC NO 1 10
31 20249 SHIM HSG BIG 5T CUB WC,AC NO 2 12
32 20250 SHIM HSG BIG 10T CUB WCAC NO 2 12
33 20267 FUEL FILTER UPTO 6.5 LWE NO 1 4
34 20265 AIR CLNR ASY SML+CLP LWE NO 1 4
35 20266 EX SILENCER FLNG LWE NO 1 4
36 A25 CON ROD 5/2600 CUB JALVEE NO 1 4
37 20113 STARTING HANDLE LWE NO 1 4
38 20216 FULCRUM PIN LWE NO 1 6
39 20225 KEY FOR CRANK GEAR LWE NO 1 12
40 20224 FLYWHEEL KEY LWE NO 1 12
41 20233 P R SET 80MM (2+1)3530TRC NO 1 6
42 17187 PIPE LO FP TO RS PPW&A NO 1 6
43 50084 BEARING CON.ROD PR  CUB5 010 NO 1 6
44 50085 BEARING CON.ROD PR CUB5 020 NO 1 6
45 20221 FUEL TANK LWE COMET WITH NO 1 2
46 52170 GOV BRKT ASSY VAR SP PORT NO 1 2
47 20148 VAR SPED RACHT ASLY CUB5W NO 1 2
