Elscint manufactures a unique feeding system for feeding of half bearings of various sizes. Half bearings of upto dia 90 mm or even more can be fed through this system. This equipment consists of an Elscint vibratory hopper feeder, two Elscint linear vibratory feeders and an Elscint small parts (conveyor) feeder. The speed of operation or the feed rate can be upto 60 pieces per minute in an oriented manner. This speed can be varied through a potentiometer. Electronic controls are provided to synchronize the speed of the various components listed above. The Elscint small parts (conveyor) feeder is used for recirculation of unused parts. A special orientation device is used for orientation of the half bearings. Upto 150 Kgs of material can be loaded in the vibratory hopper. This makes the system totally manless and the operator can be utilized to do some other work. This system has been found beneficial to various Half Bearing Manufacturers all over the world.

Elscint Counting Systems

Elscint manufactures an automatic vibratory counting system for counting of small parts like plastic caps, spouts, screws, rivets, capsules and electrical connectors, bearings, as well as heavy parts such as anchor bolts, bearing races and metal sockets. The standard equipment consists of a suitable Elscint vibratory bowl feeder, correctly chosen from a variety of Models which Elscint offers, a sensing device and an electronic reset able counter. The counter can be even upto 10 digits! And even more in case of special requirements. Counting speeds can be very high, even upto 1000 parts per minute, depending upon the component which requires counting. Once a preset number is reached, the counting can be made to stop automatically. Restart can be either manually or again automatically on receiving of a signal. This equipment finds use in various industries, namely, cosmetic, electrical, mechanical, pharmaceutical, optical, bearing and many other industries. Standard bowl feeders and counters being in ready stock, delivery times are very low and the prices are very competitive.
