Heat Actuated Trap (HAT)

Since HAT valves discharge condensate well below steam temperature, live steam losses are eliminated. For heating of temperature sensitive instruments or process fluids, the reduced temperature available for tracing simplifies operations and eliminates overheating problems. The unique ram-style plug & seat provide reliable, tight shut off longer than any other design available.

Heat Actuated Trap (HAT)

Click Here to Contact Us | or | Download Manuals

Design Features

Stainless body, fittings, spring and plug
Corrosion resistant - Long service life
Most narrow temperature band available
Compact, low mass - Fast response
Ram-type plug for tight reliable shutoff
Downstream actuator for greater sensitivity
Sensitive to temperature only
Unaffected by pressure variations
Easy installation with pipe wrench
Discharges the minimum amount of water required to prevent freeze damage

Heat Actuated Trap (HAT/RA)

Click Here to Contact Us | or | Download Manuals

Design Features

All stainless steel body, fittings, spring, and plug
Compact, low mass - Fast response
Corrosion resistant - Long service life
Most clog-resistant design available
Operates in narrow temperature band
Unaffected by pressure variations
Easy installation with pipe wrench
Operates in any orientation
Discharges the minimum amount of liquid required to keep liquid temperature within safe limits

Heat Actuated Trap with leak port (HAT/RA-LP)

Click Here to Contact Us | or | Download Manuals

Design Features

100% Factory tested
Stainless steel body, fittings, spring and plug
Compact, low mass for fast response
Corrosion resistant for long service life
Most clog resistant design available
Narrow temperature band
Modulation throughout temperature range
Sensitive to fluid temperature only
Unaffected by pressure variations
Easy to install
Operates in any orientation
Control leakage for increased sensitivety

Tube Valve Heat Actuated Trap (TV/HAT)

These valves save space, eliminate the use of extra, expensive and time consuming piping. They install in seconds. The unique ram-type plug & seat provide reliable, tight shut off longer than any other design available. TV/HAT valves are covered with our standard 36 month warranty & service policy to further reduce maintenance cost. Since TV/HAT valves discharge condensate well below steam temperature, live steam losses are eliminated. For heating of temperature sensitive instruments or process fluids, the reduced temperature available for tracing simplifies operations and eliminates overheating problems.

Tube Valve Heat Actuated Trap (TV/HAT)

Click Here to Contact Us | or | Download Manuals

Design Features

Compact, low mass for fast response
Corrosion resistant for long service life
Stainless steel body, fittings, spring and plug
Ram-type plug for tight, reliable shutoff
Eliminates live steam losses
Operates in narrow temperature band
Downstream actuator for greater sensitivity
Operating temperatures unaffected by pressure
Wide choice of set-points

Tube Valve Heat Actuated Trap (TV/HAT/RA)

The TV/HAT/RA continually senses fluid temperature and automatically modulates to maintain desired temperature. Optimum operating temperature improves system efficiency, reduces wear and conserves energy. Therm-Omega-Tech valves are designed around our exclusive Thermoloid® sensor/controller which is the most advanced and reliable thermal actuator of its type available today. All Therm-Omega-Tech valves are factory tested and calibrated to assure unsurpassed accuracy, reliability and quality.

Tube Valve Heat Actuated Trap (TV/HAT/RA)

Click Here to Contact Us | or | Download Manuals

Design Features

100% Factory tested
Stainless steel body, fittings, spring and plug
Compact, low mass for fast response
Corrosion resistant for long service life
Most clog resistant design available
Narrow temperature band
Modulation throughout temperature range
Sensitive to fluid temperature only
Unaffected by pressure variations
Easy to install
Operates in any orientation

Tube Valve Heat Actuated Trap with Leak Port (TV/HAT/RA-LP)

The TV/HAT/RA continually senses fluid temperature and automatically modulates to maintain desired temperature. Optimum operating temperature improves system efficiency, reduces wear and conserves energy. Therm-Omega-Tech valves are designed around our exclusive Thermoloid® sensor/controller which is the most advanced and reliable thermal actuator of its type available today. All Therm-Omega-Tech valves are factory tested and calibrated to assure unsurpassed accuracy, reliability and quality.

Tube Valve Heat Actuated Trap with Leak Port (TV/HAT/RA-LP)

Click Here to Contact Us | or | Download Manuals

Design Features

100% Factory tested
Stainless steel body, fittings, spring and plug
Compact, low mass for fast response
Corrosion resistant for long service life
Most clog resistant design available
Narrow temperature band
Modulation throughout temperature range
Sensitive to fluid temperature only
Unaffected by pressure variations
Easy to install
Operates in any orientation

¼" Heat Actuated Trap (ECONO/HAT-RA)

These valves save space, eliminate the use of extra, expensive and time consuming piping. They install in seconds. The unique ram-type plug & seat provide reliable, tight shut off longer than any other design available. ECONO/HAT-RA valves are covered with our standard 18 month warranty & service policy to further reduce maintenance cost. Since ECONO/HAT valves discharge condensate well below steam temperature, live steam losses are eliminated. For temperature sensitive applications, such as instrument or certain processes, the reduced temperature available for tracing simplifies operations and eliminates overheating problems.

¼" Heat Actuated Trap (ECONO/HAT-RA)

Click Here to Contact Us | or | Download Manuals

Design Features

Incredibly compact, low mass - Fast response
Corrosion resistant - Long service life
All brass body, stainless steel spring and plug
Ram-type plug for tight reliable shutoff
Eliminates live steam losses
Narrow temperature band
Downstream actuator for greater sensitivity
Operating temperatures unaffected by pressure
Wide choice of set points

½" HAT/RA-HP (EPDM Seals)

The TV/HAT/RA continually senses fluid temperature and automatically modulates to maintain desired temperature. Optimum operating temperature improves system efficiency, reduces wear and conserves energy. Therm-Omega-Tech valves are designed around our exclusive Thermoloid® sensor/controller which is the most advanced and reliable thermal actuator of its type available today. All Therm-Omega-Tech valves are factory tested and calibrated to assure unsurpassed accuracy, reliability and quality.

½" HAT/RA-HP (EPDM Seals)

Click Here to Contact Us | or | Download Manuals

Design Features

All stainless steel construction
Compact, low mass - Fast response
Corrosion resistant - Long service life
Most clog-resistant design available
Operates in narrow temperature band
Unaffected by pressure variations
Easy installation with pipe wrench
Operates in any orientation
Discharges the minimum amount of water required to keep water temperature within safe limits

½" High Sample Temperature Valve (1/2 HST)

The HST valve is typically used as a high sample temperature safety shutoff valve for process sampling. The HST valve is typically installed between the sample cooler and the sample analyzer to protect the analyzer instruments from over-temperature conditions. The HST valve has a maximum operating pressure of 3000PSIG with a maximum operating temperature of 250°F. The unique ram-style plug & seat provide reliable, tight shut off. All HST valves are covered by a 36 month prorated warranty.

½" High Sample Temperature Valve (1/2 HST)

Click Here to Contact Us | or | Download Manuals

Design Features

Stainless body, fittings, spring and plug
Corrosion resistant - Long service life
Most narrow temperature band available
Compact, low mass - Fast response
Ram-type plug for tight reliable shutoff
Sensitive to temperature only
Unaffected by pressure variations
Operates in any orientation
Easy installation with pipe wrench

½" Thermostatic Mixing/Diverting Valve (1/2 M/D-316S/S)

The Therm-Omega-Tech Model M/D temperature control valve is designed for 3-way mixing or diverting applications. For fast response, the valve is compact and low mass. Therm-Omega-Tech's valves are designed around our exclusive Thermoloid sensor/controller that automatically and accurately proportions the flow in response to fluid temperature. The Thermoloid sensor/controller is the most advanced and reliable thermal actuator of its type available today.

½" Thermostatic Mixing/Diverting Valve (1/2 M/D-316S/S)

Click Here to Contact Us | or | Download Manuals

Design Features

Open Temperature: 55ºF Temperature Set Point
Temperature Control Valve - All 316 Stainless Steel
