Value Added Products
- Gas trains
- Gas filters
- Gas pressure regulators & filter
regulators - Manual reset type gas solenoid valve
- Automatic reset type gas solenoid
valves - Slam safety shut off valve
- Contrive burner controllers
- Actuators and motorised open solenoid
valves alves - Jerk handle isolation valves
- Honeywell gas train components
- Honeywell panel & field instruments
- Flow and pressure transmitters
- Air gas ratio regulators and zero
governors
Automatic Reset Type Gas Solenoid Valves
- Extensive range of Gas Solenoid Valves for Combustion Application.
- Various versions like
Compact Construction,
Fast Opening Fast Closing,
Slow Opening Fast Closing,
Flow Adjustment
and with Closed Position Indication Switch available.
Slow Opening Models available with Slow Opening Time Adjustment and optional Rapid Stroke Setting.
- High Pressure versions available for Max. 6 Bar Pressure rating.
- Sizes available upto DN200.
Automatic Reset Type Normally Open Solenoid Valves
Item Code: EVA_NA
Used as Vent Valve Between two Safety Solenoid Valves as per Safety Regulations.
Also, have applications in Annealing Furnace applications for Nitrogen Gas.
Various Size and Pressure Rating options make the valves useful for varied applications.
EVA/NC – EVAP/NC
For Vent Application or Nitrogen / Hydrogen Blanketing Lines in Annealing Furnaces.
Normally Open Fast Opening Fast Closing type Safety Shut Off Solenoid Valves
- Sizes : DN15 to DN50
- End Connections: Threaded as per EN10226 / Rotating Flanges
- Coil Voltages : 12 VDC / 24 VDC or 12 / 24 /110 / 230 VAC
- Body : Die Cast Aluminum
- Maximum Working Pressure : 360 mbar,1 Bar, 3 Bar or 6 Bar versions available.
- Suitable for Natural Gas, LPG, Propane and other dry and non aggressive gases of the 3 families. As per EN437:2003
- Coil Protection : IP65
- Closing time Less than 1 sec
- Closed Position Indication Switch available as Option.
- Versions available for Biogas and other select Gas Mixtures
- Environment temperature rating : -15 to +60 °C
Product conformance :
In conformity with the 94/9/EC Directive (ATEX Directive)
In conformity with the 2004/108/EC Directive (Electromagnetic Compatibility)
In conformity with the 2006/95/EC Directive (Low Voltage)
Automatic Closed Type Normally Closed Gas Solenoid Valves
Item Code: EVO_NC-EVP-C-R-S-F_NC
EVP/NC – EVPF/NC & EV/NC – EVF/NC
Fast Opening Fast Closing type Safety Shut Off Solenoid Valves
- Sizes : DN15 to DN200
- End Connections:
- DN15 to DN50 : Threaded as per EN10226 / Rotating Flanges
- DN65 to DN200 : Flanged as per ISO7005 (PN16)
- Coil Voltages : 12 VDC / 24 VDC or 12 / 24 /110 / 230 VAC
- Body : Die Cast Aluminum
- Maximum Working Pressure : 200mbar,1 Bar, 3 Bar or 6 Bar versions available.
- Suitable for Natural Gas, LPG, Propane and other dry and non aggressive gases of the 3 families. As per EN437:2003
- Coil Protection : IP65
- Closing time Less than 1 sec
- Inbuilt Flow Regulator and/or Closed Position Indication Switch available as Option.
- Versions available for Biogas and other select Gas Mixtures
- Environment temperature rating : -15 to +60 °C
EVPS/NC
Similar to EVP/NC except Slow Opening Fast Closing type.
- Sizes : DN15 to DN150
- Maximum Working Pressure : 200mbar,0.5 Bar, 1 Bar, 3 Bar or 6 Bar versions available.
- Closing time Less than 1 sec
- Inbuilt Flow Regulator, Slow Opening Rapid Stroke Adjustment or Closed Position Indication Switch available as Option.
Product conformance :
EC certifi ed according to EN 161
In conformity with the 90/396/EEC Directive (Gas Directive)
In conformity with the 94/9/EC Directive (ATEX Directive)
In conformity with the 2004/108/EC Directive (Electromagnetic Compatibility)
In conformity with the 2006/95/EC Directive (Low Voltage)
