Horizontal screen profile projector

Specifications

• Model H30 / H36 / H40
• Screen size 300 / 360 / 400 mm
• Choice of work stage

Size of table

• 400*150 mm
• 500*150 mm
• 600*150 mm
• Traverse X & Y axis
• 200875 mm
• 300*100 mm
• Helix tilting movement
• +/- 15 degrees, for measuring threads
• Electronic helix attachment available
• Choice of telecentric lens
• 10X / 20X / 50X / 100X with indexable turret to hold 3 lens
